Description
INFINI is Type 2 EV Charger with CCS Socket support. It is compatible for OCPP 1.6J ,OCPP 2.01. Lite & higher.Connection Type:
- P/N/E Single Phase
Load Current:
- 32A Per Phase
7.4KW EVamp INFINI
Power Rating: 7.4KW
Connector Type: 2
Compatibility:
Description
EVamp INFINI is Type-2 EV Charger for Electric Four Wheeler. It supports CCS socket. Available in 7.4KW configuration. It is easier to install & Use.
Specifications
| Input Supply Requirement | Single Phase (P/N/PE) |
|---|---|
| Operating Voltage | 230 Vac (Nominal), Operating Range: 80–280 Vac |
| Charging Voltage | 190–265 Vac (AC Output) |
| Max Charging Current | 32A (Single Phase) |
| Max Power Output | 7.4KW |
| Socket Type / Output Connector | Type 2 Gun, IEC 62196-2 |
| Vehicles Charged | 4W |
| Ingress Protection | IP54 / IK10 (outdoor-rated, typical for AC wallbox chargers) |
| Operating Temperature | –25°C to +55°C |
| Energy Metering | Class-1 (IEC 62052-11, IEC 62053-21/23) |
| Ideal Consumption | < 3W (standby) |
| Authentication | RFID (ISO/IEC 14443A/B, MIFARE 1K), Mobile App, OCPP 1.6J / 2.0 |
| Connectivity | Wi-Fi 2.4GHz, GSM, 3G/4G LTE (M2M SIM) |
| Screen / User Interface | 4-Inch Touch Screen Display |
| Emergency Shutdown Button | Yes |
| Mounting | Wall Mount / Poll Mount |
Frequently Asked Questions
Can I use this charger at home for my EV car?
Yes! It’s perfect for home garages, apartments, and villas with 230V single-phase connections.
Will it work with my Tata Nexon EV or MG ZS?
Absolutely! It uses the standard Type-2 connector (IEC 62196-2) used by most Indian & global EVs.
How do I start charging?
🚗 Just tap your RFID, scan using the Mobilane app, or start directly from your CMS. Simple and secure!
Is it smart and remotely manageable?
📡 Yes! These chargers are compatible via OCPP 1.6/2.0J and can be managed remotely through backend software.
Is it safe to install outdoors?
🛡️ Yes! It includes earth fault, surge protection, residual current protection, and emergency stop—built for Indian conditions.
